- The 20″ diamond blade with 8″ cutting clearance allows you to breeze through concrete blocks and other masonry products in one clean cut.
- 2.2Kw single phase electric motor provides the grunt you need in any location, even the most demanding work sites.
- Fitted with a 15 amp plug . Needs a good power supply on start up.
- The enlarged sliding carriage provides a completely stable platform for large scale blocks, pavers or bricks to rest on while being cut.
- Eliminate dust with the adjustable water supply valve.
- The removable mitre guide allows you to consistently cut concrete blocks, pavers and bricks to any length or shape you require.
- The detachable base provides neat transportation options on any Ute, truck or van.
- The galvanized stand and base combined with the zinc electroplated saw arm ensures the BT Blocksaw repels rust and corrosion throughout many years of operation.
Motor Specifications:
- Teco 2.2kw single phase electric motor
- Voltage : 240 (50hz)
- Current draw ( Amps)
- Max ( Start Up) 75.81
- Minimum 5.7
- Normal 13.3
- Power Output 2200w
Blade & Cutting Specifications
- Blade size ( diameter ) 510mm / 20″
- Blade bore diameter 25.4mm / 1″
- Depth of cut: 200mm / 8″
- Length of cut: 540mm /21″
Carriage Dimensions
- Length: 360mm
- Width: 570mm
Blocksaw Dimensions
- Assembled
- Length: 1450mm
- Width: 700mm
- Height: 1550mm
- Weight: 150kg
- Packed for transportation
- Length: 1450mm
- Width: 700mm
- Height: 1070mm
- Weight: 150kg
12 Month Warranty. Made and Assembled in Australia
